- Conductor: Aluminum (A) (optionally water-blocked – WTC)
- Semiconductive screen on the conductor
- Cross-linked polyethylene (XLPE) insulation
- Semiconductive screen on the insulation
- Semiconductive water-blocking tape, applied over the insulation screen
- Metallic screen – smooth welded aluminum sheath
- Outer sheath – black color: MDPE, HDPE, LSOH
- Semiconductive sheath (optional)
.webp)
Sales sectors
Main Menu - Level 2
High and extra high voltage systems
The transmission of electricity in high voltage (HV: 36–150 kV) and extra-high voltage (EHV: 220–500 kV) networks is one of the most important technological challenges in the energy industry. This requires the use of the most advanced cable systems, which must guarantee reliability, safety and cost-effectiveness. Due to the key importance of these networks for the economy, HV and EHV systems are subject to detailed regulatory standards that ensure their long-term reliability and high quality over years of operation.
kontakt w sprawie asortymentu wysokich EN
![image.png [1.18 MB]](https://www.tele-fonika.com/storage/image/core_files/2025/3/10/73facc3fd34019388a9e18ef3bc2c6da/png/tfkable/preview/image.png)
Application of HV and EWN cables
Cables designed for HV and EWN systems are mainly used in the transmission of electricity over long distances, especially in critical infrastructure, such as power plants, large industrial facilities or in regions where it is important to limit the impact of infrastructure on the natural environment. Their use allows the creation of underground installations, which helps to minimize the visibility of the network and reduce the impact on the landscape.
TELE-FONIKA Kable is one of the leaders in the production of HV and EWN cable systems, offering cables with cross-sections up to 3000 mm² and voltage up to 500 kV, characterized by high quality and reliability, which guarantees the continuity of energy supply in demanding conditions.
As part of our offer we provide:
|
|
Design consulting |
|
Design of cable structures |
|
Comprehensive project support |
| We help you select the right cable system components, optimizing operating conditions and ensuring long-term reliability. | Including calculations of current carrying capacity and other important electrical parameters. | From the delivery of cables and accessories, through verification of cable laying technology, to installation supervision and post-assembly testing. | |||
High Voltage Power Cables with XLPE Insulation and Welded Aluminum Screen
High Voltage Power Cables with XLPE Insulation and Aluminum Wire Screen
- Conductor: Aluminum (A) (optionally water-blocked – WTC)
- Semiconductive screen on the conductor
- Cross-linked polyethylene (XLPE) insulation
- Semiconductive screen on the insulation
- Semiconductive water-blocking tape, applied over the insulation screen
- Metallic screen: Aluminum wires and tapes (optionally optical fibers in tubes)
- Semiconductive water-blocking tape, applied over the metallic screen
